Now that we have some definitions out of the way it's time to build a server.
As stated in the definitions for this series "L" represents Linux in LAMP software stack. LAMP (Linux, Apache, MySQL, PHP) is an open source software stack where each component contributes essential capabilities to an application. Though almost any OS, HTTP server, Database Manager, and data processing software could be used that suites your need the LAMP stack "has a classic layered architecture, with Linux at the lowest level followed by Apache, MySQL, and PHP. Although PHP is nominally at the top or presentation layer, the PHP component sits inside Apache." 5
Though there are a lot of options for the servers Operating System, I don't need any type of crazy set up and I don't want to spend any money. With this in mind that means that any Windows Server is out as it's about $100+; so I will stick with a Linux/Unix based OS.
As far as free server OS options it depends a lot on your intended use.
- If you want a media storage server specifically you could chose Plex Media Server, FreeNAS, or Kodi Open Source Home Theatre Software to name a few.
- If you want some flexibility you might try some server management software like Amahi Home Server that is installed on top of Fedora or CentOS servers and comes preinstalled with a lot of services already.
- If you want to configure it yourself, like me, you might choose Ubuntu Server Edition, ClearOS, or Fedora Server to name a few.
After some research on the abilities of the server software, I decided on Ubuntu Server Edition because I need something that is widely used in production environments. Now it's time to work on installing it onto an old computer I have hanging out in my office.
For server OS installs there might be an extra step here, depending on your current setup, as servers don't like to use WIFI as their main connection.
Why you ask? This is because the vast majority of NICs (Network Interface Cards) that are in computers are almost all the same, or there is very little variation, so it's easier to have the drivers already as part of the server OS at install. In contrast, basically every WIFI adapter out there is different and it would be next to pointless for an OS to come with drivers for some 200 WIFI adapters when they could have maybe 10 NIC drivers.
For my setup, this means that I need a switch to split the ethernet connection coming into my office. This is easy enough as its a plug-and-play style device and just needs to be plugged in. I take my incoming ethernet cord and plug it into slot #1 and then add another ethernet cord into slot #2 for my server computer and one more into slot #3 (respectively) for my client computer.
Thanks to the "Install Ubuntu Server" turotial all the steps are broken down nicely so I wont go into much detail here. Just follow the tutorial and it explains what you might need to do really well. For my, I did notice that some steps didn't quite look the same but it worked out just fine.
To follow the tutorial steps as best as able for my system and a basic configuration I did:
- Downloading the ISO file in the Manual install
- Burning it to a USB or CD (I used BalenaEtcher to burn the ISO to a USB)
- Install it on the desired computer following the tutorial steps.
Now that the server is installed it's good to make sure that it's all working and you can interact with it from your client.
- You can ensure it has Internet connectivity in general by running
ping 22.214.171.124(Googles DNS) or it might be evident during setup if it is connected and working as the Ubuntu Server OS I installed said it needed some updates from version 20.04 to 20.09 during the install.
- Next you might want to install the Ubuntu net-tools with
apt install net-toolson the server computer to allow the
ifconfigcommand to see your servers IP address.
- Now run the "ping" command from you client computer with the IP address of your server computer to confirm that your client can see your server.
- Next it's good to ping the server computer from your client. Being that my client is a Windows PC I ran
ipconfigin my Windows terminal to find its I address and then ran "ping" from my server computer to my client and vice versa.
- Note: you might need to restart your server and client at this point to refresh its cache. I tried refreshing the caches manually but restarting fixed an issue that wouldn't let my client PC ping my server.
Success! The Linux OS install is done and it's on to Apache.
