Canonical Kubernetes que l’on a pu aborder dans l’article précédent,
k8s-snap (Canonical Kubernetes) pour un déploiement simple et rapide d’un cluster k8s …
peut également être installé dans LXD. C’est un excellent moyen, par exemple, de tester Canonical Kubernetes en cluster sans avoir besoin de plusieurs hôtes physiques.
LXD: five easy pieces | Ubuntu
Je pars donc d’une simple instance Ubuntu 22.04 LTS dans DigitalOcean :
curl -X POST -H 'Content-Type: application/json' \
-H 'Authorization: Bearer '$TOKEN'' \
-d '{"name":"lxd",
"size":"s-4vcpu-16gb-amd",
"region":"fra1",
"image":"ubuntu-22-04-x64",
"vpc_uuid":"XXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXX"}' \
"https://api.digitalocean.com/v2/droplets"
et j’y installe et initie LXD ainsi que de l’orchestrateur Juju :
root@lxd:~# snap remove lxd --purge && snap install lxd --candidate
lxd removed
lxd (candidate) 5.21.0-eb655b9 from Canonical✓ installed
root@lxd:~# snap list
Name Version Rev Tracking Publisher Notes
core20 20230207 1828 latest/stable canonical✓ base
core22 20240111 1122 latest/stable canonical✓ base
lxd 5.21.0-eb655b9 27957 latest/candidate canonical✓ -
snapd 2.58.2 18357 latest/stable canonical✓ snapd
root@lxd:~# lxd init
Would you like to use LXD clustering? (yes/no) [default=no]:
Do you want to configure a new storage pool? (yes/no) [default=yes]:
Name of the new storage pool [default=default]:
Name of the storage backend to use (dir, lvm, powerflex, zfs, btrfs, ceph) [default=zfs]: dir
Would you like to connect to a MAAS server? (yes/no) [default=no]:
Would you like to create a new local network bridge? (yes/no) [default=yes]:
What should the new bridge be called? [default=lxdbr0]:
What IPv4 address should be used? (CIDR subnet notation, “auto” or “none”) [default=auto]:
What IPv6 address should be used? (CIDR subnet notation, “auto” or “none”) [default=auto]: none
Would you like the LXD server to be available over the network? (yes/no) [default=no]:
Would you like stale cached images to be updated automatically? (yes/no) [default=yes]:
Would you like a YAML "lxd init" preseed to be printed? (yes/no) [default=no]:
The simplest way to deploy and maintain applications in the cloud
root@lxd:~# snap install juju
juju (3/stable) 3.4.0 from Canonical✓ installed
Edition du profil par défaut dans LXD pour lui permettre de prendre en charge Canonical Kubernetes avec ce modèle …
Install Canonical Kubernetes in LXD
name: default
description: Default LXD profile
config:
boot.autostart: "true"
linux.kernel_modules: ip_vs,ip_vs_rr,ip_vs_wrr,ip_vs_sh,ip_tables,ip6_tables,iptable_raw,netlink_diag,nf_nat,overlay,br_netfilter,xt_socket
raw.lxc: |
lxc.apparmor.profile=unconfined
lxc.mount.auto=proc:rw sys:rw cgroup:rw
lxc.cgroup.devices.allow=a
lxc.cap.drop=
security.nesting: "true"
security.privileged: "true"
devices:
aadisable2:
path: /dev/kmsg
source: /dev/kmsg
type: unix-char
dev-loop-control:
major: "10"
minor: "237"
path: /dev/loop-control
type: unix-char
dev-loop0:
major: "7"
minor: "0"
path: /dev/loop0
type: unix-block
dev-loop1:
major: "7"
minor: "1"
path: /dev/loop1
type: unix-block
dev-loop2:
major: "7"
minor: "2"
path: /dev/loop2
type: unix-block
dev-loop3:
major: "7"
minor: "3"
path: /dev/loop3
type: unix-block
dev-loop4:
major: "7"
minor: "4"
path: /dev/loop4
type: unix-block
dev-loop5:
major: "7"
minor: "5"
path: /dev/loop5
type: unix-block
dev-loop6:
major: "7"
minor: "6"
path: /dev/loop6
type: unix-block
dev-loop7:
major: "7"
minor: "7"
path: /dev/loop7
type: unix-block
dev-loop8:
major: "7"
minor: "8"
path: /dev/loop8
type: unix-block
dev-loop9:
major: "7"
minor: "9"
path: /dev/loop9
type: unix-block
dev-loop10:
major: "7"
minor: "10"
path: /dev/loop10
type: unix-block
dev-loop11:
major: "7"
minor: "11"
path: /dev/loop11
type: unix-block
dev-loop12:
major: "7"
minor: "12"
path: /dev/loop12
type: unix-block
dev-loop13:
major: "7"
minor: "13"
path: /dev/loop13
type: unix-block
dev-loop14:
major: "7"
minor: "14"
path: /dev/loop14
type: unix-block
dev-loop15:
major: "7"
minor: "15"
path: /dev/loop15
type: unix-block
dev-loop16:
major: "7"
minor: "16"
path: /dev/loop16
type: unix-block
eth0:
name: eth0
network: lxdbr0
type: nic
root:
path: /
pool: default
type: disk
used_by: []
Application de ce profil par défaut dans LXD :
root@lxd:~# lxc profile edit default < lxd-profile-default.yaml
root@lxd:~# lxc profile show default
name: default
description: Default LXD profile
config:
boot.autostart: "true"
linux.kernel_modules: ip_vs,ip_vs_rr,ip_vs_wrr,ip_vs_sh,ip_tables,ip6_tables,iptable_raw,netlink_diag,nf_nat,overlay,br_netfilter,xt_socket
raw.lxc: |
lxc.apparmor.profile=unconfined
lxc.mount.auto=proc:rw sys:rw cgroup:rw
lxc.cgroup.devices.allow=a
lxc.cap.drop=
security.nesting: "true"
security.privileged: "true"
devices:
aadisable2:
path: /dev/kmsg
source: /dev/kmsg
type: unix-char
dev-loop-control:
major: "10"
minor: "237"
path: /dev/loop-control
type: unix-char
dev-loop0:
major: "7"
minor: "0"
path: /dev/loop0
type: unix-block
dev-loop1:
major: "7"
minor: "1"
path: /dev/loop1
type: unix-block
dev-loop2:
major: "7"
minor: "2"
path: /dev/loop2
type: unix-block
dev-loop3:
major: "7"
minor: "3"
path: /dev/loop3
type: unix-block
dev-loop4:
major: "7"
minor: "4"
path: /dev/loop4
type: unix-block
dev-loop5:
major: "7"
minor: "5"
path: /dev/loop5
type: unix-block
dev-loop6:
major: "7"
minor: "6"
path: /dev/loop6
type: unix-block
dev-loop7:
major: "7"
minor: "7"
path: /dev/loop7
type: unix-block
dev-loop8:
major: "7"
minor: "8"
path: /dev/loop8
type: unix-block
dev-loop9:
major: "7"
minor: "9"
path: /dev/loop9
type: unix-block
dev-loop10:
major: "7"
minor: "10"
path: /dev/loop10
type: unix-block
dev-loop11:
major: "7"
minor: "11"
path: /dev/loop11
type: unix-block
dev-loop12:
major: "7"
minor: "12"
path: /dev/loop12
type: unix-block
dev-loop13:
major: "7"
minor: "13"
path: /dev/loop13
type: unix-block
dev-loop14:
major: "7"
minor: "14"
path: /dev/loop14
type: unix-block
dev-loop15:
major: "7"
minor: "15"
path: /dev/loop15
type: unix-block
dev-loop16:
major: "7"
minor: "16"
path: /dev/loop16
type: unix-block
eth0:
name: eth0
network: lxdbr0
type: nic
root:
path: /
pool: default
type: disk
used_by: []
Suivi du lancement d’un contrôleur local dans LXD pour Juju :
root@lxd:~# mkdir -p ~/.local/share/juju
root@lxd:~# juju bootstrap localhost lxd
Creating Juju controller "lxd" on localhost/localhost
Looking for packaged Juju agent version 3.4.0 for amd64
Located Juju agent version 3.4.0-ubuntu-amd64 at https://streams.canonical.com/juju/tools/agent/3.4.0/juju-3.4.0-linux-amd64.tgz
To configure your system to better support LXD containers, please see: https://documentation.ubuntu.com/lxd/en/latest/explanation/performance_tuning/
Launching controller instance(s) on localhost/localhost...
- juju-b6d031-0 (arch=amd64)
Installing Juju agent on bootstrap instance
Waiting for address
Attempting to connect to 10.11.106.167:22
Connected to 10.11.106.167
Running machine configuration script...
Bootstrap agent now started
Contacting Juju controller at 10.11.106.167 to verify accessibility...
Bootstrap complete, controller "lxd" is now available
Controller machines are in the "controller" model
Now you can run
juju add-model <model-name>
to create a new model to deploy workloads.
root@lxd:~# juju controllers
Use --refresh option with this command to see the latest information.
Controller Model User Access Cloud/Region Models Nodes HA Version
lxd* - admin superuser localhost/localhost 1 1 none 3.4.0
root@lxd:~# lxc ls
+---------------+---------+----------------------+------+-----------+-----------+
| NAME | STATE | IPV4 | IPV6 | TYPE | SNAPSHOTS |
+---------------+---------+----------------------+------+-----------+-----------+
| juju-b6d031-0 | RUNNING | 10.11.106.167 (eth0) | | CONTAINER | 0 |
+---------------+---------+----------------------+------+-----------+-----------+
Visualisation des Charms pour Canonical Kubernetes avant installation :
root@lxd:~# juju info k8s
name: k8s
publisher: Canonical Kubernetes
summary: A machine charm for K8s
description: "A machine charm which operates a complete Kubernetes cluster.\n\nThis
charm installs and operates a Kubernetes cluster via the k8s snap. It exposes\nrelations
to co-operate with other kubernetes components such as optional CNIs, \noptional
cloud-providers, optional schedulers, external backing stores, and external\ncertificate
storage.\n\nThis charm provides the following running components:\n* kube-apiserver\n*
kube-scheduler\n* kube-controller-manager\n* kube-proxy\n* kubelet\n* containerd\n\nThis
charm can optionally disable the following components:\n* A Kubernetes Backing Store\n*
A Kubernetes CNI\n"
store-url: https://charmhub.io/k8s
charm-id: 5GG4ydqob6yLrcZ3rrscqL0gVJvK53Ij
supports: ubuntu@20.04, ubuntu@22.04
subordinate: false
relations:
provides:
cos-agent: cos_agent
cos-worker-tokens: cos-tokens
k8s-cluster: k8s-cluster
requires: {}
channels: |
latest/stable: –
latest/candidate: –
latest/beta: –
latest/edge: 26 2024-03-29 (26) 3MB amd64 ubuntu@20.04, ubuntu@22.04
root@lxd:~# juju info k8s-worker
name: k8s-worker
publisher: Canonical Kubernetes
summary: A machine charm for a K8s Worker
description: |
A machine charm which operates a Kubernetes worker.
This charm installs and operates a Kubernetes worker via the k8s snap. It exposes
relations to co-operate with other kubernetes components
This charm provides the following running components:
* kube-proxy
* kubelet
* containerd
store-url: https://charmhub.io/k8s-worker
charm-id: ZL6PvT8yleZOMih0oKRYPgQI4FntLB48
supports: ubuntu@20.04, ubuntu@22.04
subordinate: false
relations:
provides:
cos-agent: cos_agent
requires:
cluster: k8s-cluster
cos-tokens: cos-tokens
channels: |
latest/stable: –
latest/candidate: –
latest/beta: –
latest/edge: 27 2024-03-29 (27) 6MB amd64 ubuntu@20.04, ubuntu@22.04
qui peuvent être installés avec Juju, avec ici le noeud contrôleur du futur cluster Kubernetes …
Install Canonical Kubernetes from a charm
root@lxd:~# juju add-model k8s
Added 'k8s' model on localhost/localhost with credential 'localhost' for user 'admin'
root@lxd:~# juju deploy k8s --channel=latest/edge
Deployed "k8s" from charm-hub charm "k8s", revision 26 in channel latest/edge on ubuntu@22.04/stable
root@lxd:~# juju status
Model Controller Cloud/Region Version SLA Timestamp
k8s lxd localhost/localhost 3.4.0 unsupported 12:37:00Z
App Version Status Scale Charm Channel Rev Exposed Message
k8s waiting 1 k8s latest/edge 26 no Cluster not yet ready
Unit Workload Agent Machine Public address Ports Message
k8s/0* waiting idle 0 10.11.106.116 Cluster not yet ready
Machine State Address Inst id Base AZ Message
0 started 10.11.106.116 juju-85fd7d-0 ubuntu@22.04 Running
Déploiement de deux noeuds Workers :
root@lxd:~# juju deploy k8s-worker --channel=latest/edge -n 2
Deployed "k8s-worker" from charm-hub charm "k8s-worker", revision 27 in channel latest/edge on ubuntu@22.04/stable
root@lxd:~# juju integrate k8s k8s-worker:cluster
Le cluster Kubernetes est alors actif et opérationnel :
root@lxd:~# juju status
Model Controller Cloud/Region Version SLA Timestamp
k8s lxd localhost/localhost 3.4.0 unsupported 12:39:53Z
App Version Status Scale Charm Channel Rev Exposed Message
k8s 1.29.3 active 1 k8s latest/edge 26 no Ready
k8s-worker 1.29.3 active 2 k8s-worker latest/edge 27 no Ready
Unit Workload Agent Machine Public address Ports Message
k8s-worker/0* active idle 1 10.11.106.20 Ready
k8s-worker/1 active idle 2 10.11.106.178 Ready
k8s/0* active idle 0 10.11.106.116 6443/tcp Ready
Machine State Address Inst id Base AZ Message
0 started 10.11.106.116 juju-85fd7d-0 ubuntu@22.04 Running
1 started 10.11.106.20 juju-85fd7d-1 ubuntu@22.04 Running
2 started 10.11.106.178 juju-85fd7d-2 ubuntu@22.04 Running
Connexion au noeud Contrôleur du cluster pour vérifier son statut :
root@lxd:~# juju ssh k8s/0
The programs included with the Ubuntu system are free software;
the exact distribution terms for each program are described in the
individual files in /usr/share/doc/*/copyright.
Ubuntu comes with ABSOLUTELY NO WARRANTY, to the extent permitted by
applicable law.
To run a command as administrator (user "root"), use "sudo <command>".
See "man sudo_root" for details.
ubuntu@juju-85fd7d-0:~$ sudo k8s status
status: ready
high-availability: no
datastore:
voter-nodes:
- 10.11.106.116:6400
standby-nodes: none
spare-nodes: none
network:
enabled: true
dns:
enabled: true
cluster-domain: cluster.local
service-ip: 10.152.183.28
upstream-nameservers:
- /etc/resolv.conf
metrics-server:
enabled: true
ubuntu@juju-85fd7d-0:~$ sudo k8s kubectl cluster-info
Kubernetes control plane is running at https://127.0.0.1:6443
CoreDNS is running at https://127.0.0.1:6443/api/v1/namespaces/kube-system/services/coredns:udp-53/proxy
To further debug and diagnose cluster problems, use 'kubectl cluster-info dump'.
ubuntu@juju-85fd7d-0:~$ sudo k8s kubectl get nodes -o wide
NAME STATUS ROLES AGE VERSION INTERNAL-IP EXTERNAL-IP OS-IMAGE KERNEL-VERSION CONTAINER-RUNTIME
juju-85fd7d-0 Ready control-plane,worker 7m10s v1.29.3 10.11.106.116 <none> Ubuntu 22.04.4 LTS 5.15.0-67-generic containerd://1.6.28
juju-85fd7d-1 Ready worker 3m23s v1.29.3 10.11.106.20 <none> Ubuntu 22.04.4 LTS 5.15.0-67-generic containerd://1.6.28
juju-85fd7d-2 Ready worker 3m10s v1.29.3 10.11.106.178 <none> Ubuntu 22.04.4 LTS 5.15.0-67-generic containerd://1.6.28
ubuntu@juju-85fd7d-0:~$ sudo k8s kubectl get po,svc -A
NAMESPACE NAME READY STATUS RESTARTS AGE
kube-system pod/cilium-b5hkt 1/1 Running 0 7m13s
kube-system pod/cilium-gghfz 1/1 Running 0 3m17s
kube-system pod/cilium-kzwpz 1/1 Running 0 3m30s
kube-system pod/cilium-operator-597b55b886-jhqkq 1/1 Running 0 7m13s
kube-system pod/coredns-66579b5b88-x9dv2 1/1 Running 0 7m13s
kube-system pod/metrics-server-57db9dfb7b-lnllv 1/1 Running 0 7m13s
NAMESPACE NAME TYPE CLUSTER-IP EXTERNAL-IP PORT(S) AGE
default service/kubernetes ClusterIP 10.152.183.1 <none> 443/TCP 7m20s
kube-system service/coredns ClusterIP 10.152.183.28 <none> 53/UDP,53/TCP 7m21s
kube-system service/hubble-peer ClusterIP 10.152.183.184 <none> 443/TCP 7m21s
kube-system service/metrics-server ClusterIP 10.152.183.60 <none> 443/TCP 7m20s
Je peux récupérer le fichierkubeconfigavec Juju :
root@lxd:~# juju ssh k8s/0 'sudo k8s config'
apiVersion: v1
clusters:
- cluster:
certificate-authority-data: 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
server: https://10.11.106.116:6443
name: k8s
contexts:
- context:
cluster: k8s
user: k8s-user
name: k8s
current-context: k8s
kind: Config
preferences: {}
users:
- name: k8s-user
user:
token: token::00669e4efab3674984256068943beee135d06d1a
Connection to 10.11.106.116 closed.
Pour bénéficier localement du client kubectl :
root@lxd:~# juju expose k8s
root@lxd:~# snap install kubectl --classic
snap "kubectl" is already installed, see 'snap help refresh'
root@lxd:~# mkdir .kube
root@lxd:~# juju ssh k8s/0 'sudo k8s config' > .kube/config
Connection to 10.11.106.116 closed.
root@lxd:~# chmod 400 .kube/config
root@lxd:~# kubectl cluster-info
Kubernetes control plane is running at https://10.11.106.116:6443
CoreDNS is running at https://10.11.106.116:6443/api/v1/namespaces/kube-system/services/coredns:udp-53/proxy
To further debug and diagnose cluster problems, use 'kubectl cluster-info dump'.
root@lxd:~# kubectl get nodes -o wide
NAME STATUS ROLES AGE VERSION INTERNAL-IP EXTERNAL-IP OS-IMAGE KERNEL-VERSION CONTAINER-RUNTIME
juju-85fd7d-0 Ready control-plane,worker 11m v1.29.3 10.11.106.116 <none> Ubuntu 22.04.4 LTS 5.15.0-67-generic containerd://1.6.28
juju-85fd7d-1 Ready worker 7m47s v1.29.3 10.11.106.20 <none> Ubuntu 22.04.4 LTS 5.15.0-67-generic containerd://1.6.28
juju-85fd7d-2 Ready worker 7m34s v1.29.3 10.11.106.178 <none> Ubuntu 22.04.4 LTS 5.15.0-67-generic containerd://1.6.28
root@lxd:~# lxc ls
+---------------+---------+--------------------------+------+-----------+-----------+
| NAME | STATE | IPV4 | IPV6 | TYPE | SNAPSHOTS |
+---------------+---------+--------------------------+------+-----------+-----------+
| juju-85fd7d-0 | RUNNING | 10.11.106.116 (eth0) | | CONTAINER | 0 |
| | | 10.1.0.231 (cilium_host) | | | |
+---------------+---------+--------------------------+------+-----------+-----------+
| juju-85fd7d-1 | RUNNING | 10.11.106.20 (eth0) | | CONTAINER | 0 |
| | | 10.1.1.16 (cilium_host) | | | |
+---------------+---------+--------------------------+------+-----------+-----------+
| juju-85fd7d-2 | RUNNING | 10.11.106.178 (eth0) | | CONTAINER | 0 |
| | | 10.1.2.20 (cilium_host) | | | |
+---------------+---------+--------------------------+------+-----------+-----------+
| juju-b6d031-0 | RUNNING | 10.11.106.167 (eth0) | | CONTAINER | 0 |
+---------------+---------+--------------------------+------+-----------+-----------+
Comme dans l’article précédent, je peux bénéficier d’Ollama et des LLM ouverts via Helm :
root@lxd:~# curl https://raw.githubusercontent.com/helm/helm/main/scripts/get-helm-3 | bash
Downloading https://get.helm.sh/helm-v3.14.3-linux-amd64.tar.gz
Verifying checksum... Done.
Preparing to install helm into /usr/local/bin
helm installed into /usr/local/bin/helm
root@lxd:~# helm ls
NAME NAMESPACE REVISION UPDATED STATUS CHART APP VERSION
root@lxd:~# kubectl create namespace ollama
namespace/ollama created
root@lxd:~# helm install ollama ollama-helm/ollama --namespace ollama
NAME: ollama
LAST DEPLOYED:
NAMESPACE: ollama
STATUS: deployed
REVISION: 1
NOTES:
1. Get the application URL by running these commands:
export POD_NAME=$(kubectl get pods --namespace ollama -l "app.kubernetes.io/name=ollama,app.kubernetes.io/instance=ollama" -o jsonpath="{.items[0].metadata.name}")
export CONTAINER_PORT=$(kubectl get pod --namespace ollama $POD_NAME -o jsonpath="{.spec.containers[0].ports[0].containerPort}")
echo "Visit http://127.0.0.1:8080 to use your application"
kubectl --namespace ollama port-forward $POD_NAME 8080:$CONTAINER_PORT
root@lxd:~# helm ls --namespace ollama
NAME NAMESPACE REVISION UPDATED STATUS CHART APP VERSION
ollama ollama 1 2024-03-31 13:11:43.199405708 +0000 UTC deployed ollama-0.21.1 0.1.30
root@lxd:~# kubectl get po,svc -n ollama
NAME READY STATUS RESTARTS AGE
pod/ollama-75c7b79658-rnf7h 1/1 Running 0 94s
NAME TYPE CLUSTER-IP EXTERNAL-IP PORT(S) AGE
service/ollama ClusterIP 10.152.183.78 <none> 11434/TCP 94s
Et je peux exposer localement l’API RESTful d’Ollama :
root@lxd:~# kubectl port-forward service/ollama -n ollama 11434:11434 --address='0.0.0.0'
Forwarding from 0.0.0.0:11434 -> 11434
root@lxd:~# netstat -tunlp
Active Internet connections (only servers)
Proto Recv-Q Send-Q Local Address Foreign Address State PID/Program name
tcp 0 0 0.0.0.0:22 0.0.0.0:* LISTEN 1399/sshd: /usr/sbi
tcp 0 0 10.11.106.1:53 0.0.0.0:* LISTEN 9929/dnsmasq
tcp 0 0 0.0.0.0:11434 0.0.0.0:* LISTEN 52634/kubectl
tcp 0 0 127.0.0.53:53 0.0.0.0:* LISTEN 623/systemd-resolve
tcp6 0 0 :::8443 :::* LISTEN 9784/lxd
tcp6 0 0 :::22 :::* LISTEN 1399/sshd: /usr/sbi
udp 0 0 10.11.106.1:53 0.0.0.0:* 9929/dnsmasq
udp 0 0 127.0.0.53:53 0.0.0.0:* 623/systemd-resolve
udp 0 0 0.0.0.0:67 0.0.0.0:* 9929/dnsmasq
Récupération du client Ollama via GitHub :
root@lxd:~# wget -c https://github.com/ollama/ollama/releases/download/v0.1.30/ollama-linux-amd64 && chmod +x ollama-linux-amd64 && mv ollama-linux-amd64 /usr/local/bin/ollama
Resolving objects.githubusercontent.com (objects.githubusercontent.com)... 185.199.111.133, 185.199.108.133, 185.199.109.133, ...
Connecting to objects.githubusercontent.com (objects.githubusercontent.com)|185.199.111.133|:443... connected.
HTTP request sent, awaiting response... 200 OK
Length: 297108760 (283M) [application/octet-stream]
Saving to: ‘ollama-linux-amd64’
ollama-linux-amd64 100%[=====================================================================================================>] 283.34M 351MB/s in 0.8s
(351 MB/s) - ‘ollama-linux-amd64’ saved [297108760/297108760]
Pour exécuter par exemple ici Code Llama, une famille de LLM pour le code basée sur Llama 2 :
root@lxd:~# ollama run codellama
pulling manifest
pulling 3a43f93b78ec... 100% ▕██████████████████████████████████████████████████████████████████████████████████████████████████████████████████████████████▏ 3.8 GB
pulling 8c17c2ebb0ea... 100% ▕██████████████████████████████████████████████████████████████████████████████████████████████████████████████████████████████▏ 7.0 KB
pulling 590d74a5569b... 100% ▕██████████████████████████████████████████████████████████████████████████████████████████████████████████████████████████████▏ 4.8 KB
pulling 2e0493f67d0c... 100% ▕██████████████████████████████████████████████████████████████████████████████████████████████████████████████████████████████▏ 59 B
pulling 7f6a57943a88... 100% ▕██████████████████████████████████████████████████████████████████████████████████████████████████████████████████████████████▏ 120 B
pulling 316526ac7323... 100% ▕██████████████████████████████████████████████████████████████████████████████████████████████████████████████████████████████▏ 529 B
verifying sha256 digest
writing manifest
removing any unused layers
success
Avec ces petits exemples à parfaire …
>>> How deploy manifest with Juju inside Kubernetes cluster ?
To deploy a manifest file with Juju inside a Kubernetes cluster, you can follow these steps:
1. Install Juju on your local machine and connect it to the Kubernetes cluster that you want to deploy the manifest file to.
2. Create a Juju model for the Kubernetes cluster by running the following command:
juju add-model <cluster-name>
Replace `<cluster-name>` with the name of your Kubernetes cluster.
3. Set the deployment environment to the Kubernetes cluster that you want to deploy the manifest file to by running the following command:
juju set-environment <cluster-name>
4. Create a new Juju application using the `juju add` command, passing in the name of the application and the path to the manifest file as arguments. For example:
juju add my-application manifests/my-application.yaml
Replace `<my-application>` with the name of your application and `<manifests/my-application.yaml>` with the path to your manifest file.
5. Deploy the application by running the following command:
juju deploy my-application
This will deploy the application using the configuration specified in the manifest file.
6. Once the deployment is complete, you can manage the application using standard Juju commands, such as `juju status` to view the status of the application and `juju logs` to view the
logs for the application.
7. To remove the application from the Kubernetes cluster, you can use the `juju destroy` command:
juju destroy my-application
This will destroy the application and all its resources in the Kubernetes cluster.
Note that this is a basic example of how to deploy a manifest file with Juju inside a Kubernetes cluster. There are many other options and features available in Juju, so you can
explore those as well.
>>> How deploy a Pod with Rust inside Kubernetes ?
To deploy a Pod with Rust inside a Kubernetes cluster, you can follow these steps:
1. Install the `cargo` package on your local machine by running the following command:
sudo apt-get install cargo
2. Create a new Rust project using the `cargo new` command, passing in the name of your project as an argument. For example:
cargo new my-rust-project
3. Change into the directory of your new project by running the following command:
cd my-rust-project
4. Add the `kubernetes` crate to your projects dependencies by adding the following line to your `Cargo.toml` file:
[dependencies]
kubernetes = "0.18"
5. Create a new Rust file for your Kubernetes deployment, such as `deployment.rs`, and add the following code to it:
use kubernetes::api::Api;
use kubernetes::config::Configuration;
use kubernetes::apis::CoreApi;
fn main() {
let config = Configuration::new("https://<your-kubernetes-cluster>");
let client = Api::all(config);
let pod = client.create_namespaced_pod(
"default",
&Api::Pod("my-rust-deployment"),
None,
);
}
Replace `<your-kubernetes-cluster>` with the URL of your Kubernetes cluster.
6. Compile your Rust code by running the following command:
cargo build --release
7. Run your Rust code by running the following command:
./target/release/deployment
This will deploy a new Pod with Rust inside the `default` namespace of your Kubernetes cluster. You can view the status of your Pod using the `kubectl get pods` command.
Note that this is a basic example of how to deploy a Pod with Rust inside a Kubernetes cluster. There are many other options and features available in Rust, so you can explore those as
well
>>> Send a message (/? for help)
Canonical Kubernetes peut également être installé à l’intérieur d’un conteneur LXD en utilisant le profil énoncé çi-dessus comme le précise cette documentation détaillée …
Install Canonical Kubernetes in LXD
Sans compter qu’Ollama et une interface graphique conviviale avec Open WebUI pourraient être installé via Snap ou Helm :
À suivre !
Top comments (0)
