JSON Patch vs JSON Merge Patch - In-Depth Comparison

#architecture #tutorial

JSON Patch (RFC 6902) and JSON Merge Patch (RFC 7386) are two mechanisms for modifying JSON documents. Both are widely used for partial updates to resources in APIs, but they differ significantly in structure, use cases, and behavior. Here's a detailed comparison, covering their strengths, weaknesses, and examples of when to use each.

Overview

In case you are unfamiliar with either format, here's a brief overview.

JSON Patch: A fine-grained, operation-based method that specifies a list of operations (add, remove, replace, etc.) to apply to a JSON document.
JSON Merge Patch: A simpler method that describes modifications by submitting a new version of the JSON object, where only the fields that are changing are included.

Structure

JSON Patch

JSON Patch defines a sequence of operations to perform on the document. Each operation includes a path to the field being modified and the type of modification.
Operations supported by JSON Patch:
Add: Insert a new value at a given path.
Remove: Remove a value from a given path.
Replace: Replace the value at a given path.
Move: Move a value from one path to another.
Copy: Copy a value from one path to another.
Test: Test if a value exists at a given path (useful for conditional updates).

Example of JSON Patch

[
  { "op": "replace", "path": "/name", "value": "Adrian" },
  { "op": "add", "path": "/email", "value": "adrian@example.com" },
  { "op": "remove", "path": "/address/street" }
]

In this example:

The name is replaced.
The email field is added.
The street within the address object is removed.

JSON Merge Patch

JSON Merge Patch involves submitting a modified version of the document where fields that aren't modified are omitted, and fields that are removed are explicitly set to null.
It uses a much simpler format but is less granular than JSON Patch. You cannot explicitly define operations like "move" or "test."

Example of JSON Merge Patch

{
  "name": "Adrian",
  "email": "adrian@example.com",
  "address": {
    "street": null
  }
}

In this example:

The name is updated to "Adrian".
The email field is added.
The street field under address is removed by setting it to null.

If you'd like to test out JSON Merge Patch for yourself, check out our new > JSON Merge Patch tool and API.

Strengths

JSON Patch Strengths

Fine-Grained Control: JSON Patch is more powerful for complex operations since it allows fine-grained modifications such as move, copy, and test.
Conditional Updates: The test operation can be used for conditional updates, making it suitable for scenarios where changes must be validated before being applied. The test command is especially useful in validating that sensitive/protected fields were not modified or deleted.
Precision: Operations such as replacing a specific array element or deeply nested field are handled explicitly.

JSON Merge Patch Strengths

Simplicity: JSON Merge Patch is simpler to understand and implement because it mirrors the structure of the original document. It's more intuitive when updating a large section of a document.
Ease of Use: For basic use cases like modifying or removing fields, JSON Merge Patch is much easier to use. There's no need to specify the exact operation to be performed.
Efficiency: When making straightforward changes like adding or modifying a few fields, JSON Merge Patch reduces complexity compared to JSON Patch - and also can be represented in a much more compact structure, saving bandwidth.

Weaknesses

JSON Patch Weaknesses

Complexity: The operation-based structure makes JSON Patch harder to work with for developers unfamiliar with the format. It's overkill for simple updates.
Bulk Updates: For large objects with many fields to update, JSON Patch requires multiple operations, which can be verbose and harder to manage.
Error-Prone: If the path is incorrect or doesn't exist, operations can fail. The need to be very precise with paths adds room for mistakes, especially if you're less familiar with JSON Pointer.

JSON Merge Patch Weaknesses

Lack of Fine Control: JSON Merge Patch lacks the ability to perform complex operations like moving or copying fields.
Ambiguity in Arrays: JSON Merge Patch does not have explicit support for array modifications, which can be limiting when working with arrays.
Limited Conditional Support: There’s no mechanism like the test operation in JSON Patch, meaning updates are always applied without conditional checks. This required additional code to protect sensitive fields from modification or deletion.

Use Cases

When to Use JSON Patch

Complex Modifications: JSON Patch is ideal for scenarios where multiple fields need to be modified with different operations like add, replace, and remove. For example, updating a deeply nested field or handling arrays requires the explicit path-based control JSON Patch offers via JSON Pointer.
Conditional Updates: When you need to verify a specific condition before applying an update, JSON Patch’s test operation is invaluable.
Partial Changes to an Array: JSON Patch allows you to modify or replace individual elements within an array, something JSON Merge Patch struggles with.

Example

A REST API that allows users to update specific fields of a document or perform conditional updates would benefit from JSON Patch.

[
  { "op": "replace", "path": "/address/zip", "value": "12345" },
  { "op": "test", "path": "/email", "value": "adrian@example.com" }
]

In this case, the update to the zip is applied only if the email matches.

When to Use JSON Merge Patch

Simple Updates: For straightforward cases like adding or updating a few fields in a document, JSON Merge Patch’s simplicity makes it a better fit.
Updating Large Objects: JSON Merge Patch is better when large portions of the document need to be replaced. You can submit a modified version of the document without explicitly listing each operation.
APIs with Dynamic Fields: In cases where clients only know parts of the structure and need to update some fields, JSON Merge Patch can easily be used to modify just the known fields.

Example

A REST API that allows users to update their profile would use JSON Merge Patch to update fields without specifying operations:

{
  "name": "Adrian",
  "phone": "555-1234"
}

In this case, only the name and phone fields are changed; the rest of the profile remains unaffected.

Real World API Examples

It's typically helpful to see what APIs implementing a pattern actually look like. You can always reach out to their support teams or devs on LinkedIn to inquire about challenges they faced. Here's examples of each.

JSON Patch Example: Every Action API

The Every Action API has a dedicated page to their implementation of JSON Patch, including a guide.

JSON Merge Patch Example: Worklio

Similarly, the Worklio API has a dedicated page to their implementation of JSON Merge Patch, with detailed examples.

Conclusion

Use JSON Patch when you need precise control over the modifications, especially for complex operations, including conditions and handling array elements.
Use JSON Merge Patch for simplicity and ease of use when performing basic updates on a JSON document or when the structure is large and only small changes are needed.

Each patching mechanism has its advantages depending on the complexity of the operation and the structure of the document. If you're looking to implement JSON Merge Patch or JSON Patch across your APIs or just want to modernize your APIs more generally, and want advice from an API expert - get in touch.
